Today I'll show you how to implement a video call app in less than an hour using WebRTC. If you just want to see the code, here's the repo.

What's WebRTC?

RTC stands for Real-Time Communication. It is a set of APIs provided by the browser that allow you to create a peer-to-peer (P2P) connection. It is a direct connection between two devices, which means that your private data won't go through a third-party server.

What do I need?

In order to follow this lesson, you'll need some programming experience.

• For the front-end some familiarity with Javascript and HTML is required.
• For the server, you'll benefit from any experience using express and socket.io.

Setup the initial project structure

To save us some time I've created a repo with an

Go ahead and clone it:

git clone -b initial git@github.com:ngonzalvez/aloha.git

and install the dependencies:

cd aloha
npm install

Here's what you'll find after cloning the repo:

• public/main.js
  Front-end logic.
• public/styles.css
  CSS styles for the app.
• views/room.ejs
  The template for the main UI.
• server.ts
  The server code.

Let's define some routes

For our web-app to work we need to add two routes to

• /
  It simply redirects you to a new room.
• /room/:roomId
  The meeting room.

To define these routes, add the following code to

import { v4 as uuidv4 } from "uuid";

app.get("/", (_, res) => {
  // Redirect the user to a new room.
  res.redirect(`/room/${uuidv4()}`);
});

app.get("/room/:roomId", (req, res) =>
  // Render the room template.
  res.render("room", { roomId: req.params.roomId })
);

If you run

The User Interface

If you check

<video id="active-participant" autoplay></video>
<div id="participants"></div>

Most of the UI is a big video player that will show the active participant. Set the active video stream using the

There's also a small container at the bottom. When a new participant joins the meeting, we will add his video stream to the

Lights, camera, action!

Before we implement the P2P connection, we need to get access to our camera and microphone.

When the DOM finishes loading, the

The code looks something like this:

let localStream = null;

async function init() {
  // Get access to our local video stream.
  localStream = await navigator.mediaDevices.getUserMedia({
    video: true,
    audio: true,
  });

  // Show it in the main player.
  setActiveParticipantStream(localStream);

  // Add the stream to the `participants` container.
  addParticipantStream(localStream, "me");
}

window.onload = init;

Note that we store the local video stream in a global variable, so that it is accessible from other functions as well.

Go ahead and try it. Refresh the page and you should be able to see yourself.

How does WebRTC work?

Creating P2P connections with WebRTC is quite straight forward. One peer creates a connection offer and sends it, the other peer replies with an answer, they exchange ICE candidates which are instructions on how to get from one peer to the other through the internet, and voilá, WebRTC does the rest.

There's just one issue, we need a way for the peers to send the offer and answer to each other. That's where the signaling server comes into play. The signaling server is simply a server that both peers connect to and it relays messages (signals).

Signaling Server

We'll implement the signaling server using WebSocket. If you go to

Joining the room

When a user wants to join a room, he will send a

socket.on("JoinRoom", (roomId: string) => {
  // Notify everyone in the room.
  socket.to(roomId).emit("UserJoined", socket.id);

  // Add the user to the room.
  socket.join(roomId);
});

Leaving the room

Let's also notify the room when a user disconnects. We need to know the

socket.on("disconnect", () => {
  socket.to(roomId).emit("UserLeft", socket.id);
});

Sending signals

Every time a peer wants to send an offer, answer or ICE candidate to the other peer, it will send a

socket.on("Signal", (peerId: string, message: any) => {
  // Relay the message to the other peer.
  socket.to(peerId).emit("Signal", socket.id, message);
});

And that's all there is to the signaling server.

Creating a WebRTC connection

In

• peerId
  the ID of the peer it is connecting to.
• type
  one of
  offer
  or
  answer
  .
• receivedOffer
  only used when creating an
  answer
  .

Create the RTC connection

The first thing it will do is to create a

// peerId ➡ connection map.
const peers = {};

async function createPeerConnection(peerId, type, remoteOffer) {
  const conn = (peers[peerId] = new RTCPeerConnection({
    iceServers: [{ urls: "stun:stun.l.google.com:19302" }],
  }));

  // Setup the connection here...
}

Now that we have a connection instance, I'll work you through the steps to set it up.

Send ICE candidates

When WebRTC discovers possible ICE candidates (paths from the internet to the peer), it needs to send them to the other peer, so that they are able to connect.

conn.onicecandidate = ({ candidate }) => {
  if (candidate) {
    // Send it to the other peer.
    socket.emit('Signal', peerId, { candidate});
  }
};

Handle incoming audio/video tracks

When we receive media tracks, we need to create a

// Create a multimedia stream.
const remoteStream = new MediaStream();

conn.ontrack = (event) => {
  // Get the stream from the `ontrack` event.
  const [stream] = event.streams;

  // Add the received audio/video track to the stream.
  stream.getTracks().forEach(track => {
    remoteStream.addTrack(track);
  });
};

// Display the remote stream in the UI.
addParticipantStream(remoteStream, peerId);

Send the local camera stream

In order for the other peer to receive our camera stream, we need to attach its audio and video tracks to the connection.

// Attach the media tracks from the camera stream
// to the connection.
localStream.getTracks().forEach(track => {
  conn.addTrack(track, localStream);
});

Creating an offer/answer

If this peer is the one initiating the connection, we need to create an offer, otherwise, we'll create an answer. Remember that the function signature includes a

// If there is an offer from the remote peer, set it in the connection.
if (remoteOffer) conn.setRemoteDescription(remoteOffer);

// Create the offer/answer.
const localDescription = type === "offer"
  ? await conn.createOffer()
  : await conn.createAnswer();

// Set the local offer/answer in the connection.
conn.setLocalDescription(localDescription);

// Send it to the other peer.
socket.emit(
  "Signal",
  peerId,
  { [type]: localDescription },
);

Now you have completed the implementation of the

Connecting the peers

The final step is to write the code to connect the peers using the signaling server we just implemented. The flow is as follows.

Joining a room

Once the app loaded, we'll send the

socket.emit("JoinRoom", roomId);

The signaling server will then send a

When a user joined

If a user joined, we need to send a connection offer using

socket.on("UserJoined", async (peerId) => {
  await createPeerConnection(peerId, "offer");
});

When a Signal is received

We need to reply every

socket.on("Signal", async (peerId, message) => {
  if (message.offer) {
    await createPeerConnection(peerId, "answer", message.offer);
  }
});

But a signal may also contain an

if (message.answer) {
  peers[peerId].setRemoteDescription(message.answer);
}
if (message.candidate) {
  peers[peerId].addIceCandidate(message.candidate);
}

When a user leaves

Finally, we need to handle the case when a user leaves. We simply close the connection, delete the connection from the map and remove the video stream from the UI.

socket.on("UserLeft", (peerId) => {
  // Close the connection.
  peers[peerId].close();
  delete peers[peerId];

  // Remove the video stream from the UI.
  document.querySelector(`[data-peer-id="${peerId}"]`).remove();
});

And that's it. We have implemented our very own Zoom clone using WebRTC.
